The DC Field Facility offers sample environments ranging from 20 mK to 800 C.
This system is used in conjunction with the 25 tesla split-helix magnet in cell 5.
The 3He insert system is a top-loading into liquid sorbtion pumped 3He cryostat. The temperature range of the insert is .3 K to 80 K.
This is a sample in liquid, top-loading cryostat available for use in the 41 tesla resistive magnet.
The top inlet fitting is a 3-inch nominal ladish flange and the helium bath pump port uses a NW 50 flange. Helium 3 cryostats and helium 4 vacuum cans…
This 32 mm bore magnet furnace up to 600 Celsius has 11 mm clear sample space for cells 2, 8, 12, and 15.
This 50 mm bore magnet furnace up to 600 Celsius has 19 mm clear sample space for cells 6, 7 and 9.
The Janis 13” (model CNDT) is a general purpose liquid helium 4 dewar used with the DC Field resistive 32 mm bore and 50 mm bore magnets.
This system can be used with the 30 tesla magnet in cell 2 or the 45 tesla magnet in cell 15.
A portable dilution refrigerator (PDF) is available for use in the 35 T magnet (Cell 8) and in the 45 T Hybrid Magnet (Cell 15).
The 3He insert system is a top-loading into liquid sorbtion pumped 3He cryostat. The temperature range of the insert is 0.3 K to 80 K.
A top-loading dilution refrigerator is permanently installed in an 18/20 T superconducting magnet and located in the Millikelvin Facility.
The SCM2 is a general purpose superconducting magnet with Variable Temperature Insert (VTI) and a 3He insert.
This instrumentation is used in conjunction with the 17 tesla superconducting magnet for optics (SCM3)
A top-loading dilution refrigerator can be installed in the 32T superconducting magnet. It has a base temperature of 14 mK and 400 μwatts of cooling p…
A VTI with controllable temperature range from 1.4K to 300K can be installed in the 32T superconducting magnet.
